Bates Cargo Pak Flex Airbags
Solution Group
- Products
- Services
- Integration
- Automation
-
pack
-
bundle
-
unitize
-
warehouse
-
transport
Regional Availability
Eco Friendly
Manufactured with 100% recyclable materials in a factory powered by wind energy
Narrow Gaps
Flex airbags are suitable for one-way use and are great in narrow gaps
Quality Materials
Two layers of special paper and quality film providing the highest strength
Easy Inflation
Equipped with a patented valve, can be turned 360 degrees making it possible to inflate from all angles
Flex Airbags
One time use airbags which are simple to deflate and remove with a fast puncture, used to secure cargo, which is to be transported by container or road and is at risk of being exposed to loads up to 12 tons. Available in several different sizes for your requirements. The valve is patented and is designed to close immediately after inflation to provide fast and user friendly use.
Features and Benefits
- High Wet Strength and High Friction
Due to the high friction materials the airbags stay in position during transit, the combination of materials also provide very high wet strength. - Fast Inflation and Deflation
Fast filling times, can be inflated in up to 11 seconds. Easy to deflate. - For all Climates
Suitable for use in all climatic conditions and can withstand up to 90% (RH) humidity at 60 degrees Celsius. - High Strength
The maximum load depends on the size of the airbag and the gap between the cargo see the table below. - Working Pressure
The maximum recommended working pressure is 0,2 bar (2,9 psi). Compared with the high bursting pressure this gives a security margin of factor 3-8 depending on the gap. During inflation, consideration should be given to whether the cargo and packaging can withstand the selected working pressure.
Technical Specifications
| Weight and Dimensions | |||||||
|---|---|---|---|---|---|---|---|
| Size in cm | 60 x 110 | 85 x 120 | 85 x 185 | 100 x 120 | 100 x 150 | 100 x 185 | 120 x 220 |
| Pcs. per carton | 50 | 35 | 30 | 30 | 30 | 25 | 20 |
| Pcs. per pallet | 400 | 280 | 240 | 240 | 240 | 200 | 160 |
| Gross Weight/cart. | 21.4 | 22.4 | 28.6 | 22.4 | 27.4 | 27.9 | 26.5 |
| Gross Weight/pall. | 184 | 192 | 241 | 192 | 232 | 236 | 225 |
| Inflation Times | |
|---|---|
| 60 x 110 | 11 seconds |
| 100 x 220 | 46 seconds |
In the table above filling time is based on a 3/4” hose and a pressure of 4 bar (56 psi). Maximum recommended airline pressure 6 bar.
| Maximum Load | ||||||||
|---|---|---|---|---|---|---|---|---|
| Size in cm | 60 x 110 | 85 x 120 | 85 x 185 | 100 x 120 | 100 x 150 | 100 x 185 | 100 x 220 | |
| Load in tons in a gap of: | 10 cm | 3.0 | 5.3 | 8.7 | 6.4 | 8.3 | 10.4 | 12.6 |
| 20 cm | 1.3 | 2.8 | 6.2 | 3.6 | 4.9 | 6.4 | 7.8 | |
| 45 cm | 0.4 | 0.6 | 0.9 | 1.2 | ||||
| Max. gap in cm | 25 | 37 | 37 | 45 | 45 | 45 | 45 | |
